7B Tumble Blaster

LS 7-B Tumble Blaster - LS Products

Product Overview

The 7B Tumble Blaster has an all steel cabinet construction with a wear resistant cabinet liner
and a rubber liner in areas of secondary shot deflection. The unit has balanced impeller wheel assembly (hub, impeller blades, bearings, seals, seal plates) and the wheel well is lined with replaceable wear plate material. The unit has double walled bearing protection with seals and a full load of abrasive media. A large air intake for cooler operation and more efficient dust collection is also available.

View a Product Video

Why Choose LS Industries?

Customer Service
Global Network
Warranty on all work

Questions? Ask an expert.

Our sales staff are ready to help!

800-835-0218

Features

Hardened Grate Basket



Direct Shot Impact Zone is Lined for Wear Resistance



Secondary Impact Zones are Lined With Rubber



Door Safety Automatic Shut Off



Shot Load Indicating Ammeter



LS TurboShotTM Blast Wheel Design – High Volume, Bi-Directional, Medium Velocity Blast Wheel.



Robust Design with Easy Maintenance



Belt Driven to Protect Motor

Technical Specifications

Work Envelope (Cubic Foot of Basket)

7cf

Overall Dimensions

62″ x 46″ x 78″

HP of Blast Wheels (STD)*

1ea x 10HP

Basket HP (STD)

1/2HP (0.37kw)

Standard Basket Screen

15/16″ x 1-3/4″

Dust Collector Std**

DC-1 (1HP)
